Sensitive scintillation detectors and GP for radiation mapping over varied terrain.

  • Light weight and easy to use.
  • Count rate display with alarms.
  • On the spot spectrum analysis.
  • Robust & weatherproof.
  • Touch screen PDA.
  • Long battery life.
  • Sub meter GPS accuracy.
  • 1GB SD card for data storage & transfer.
  • 1024 channel MCA.
Detector 3” NaI (2” options available)
Typical Minimum Detectable Activities (soil)150 mm  Source-detector separation 137Cs     4.1 kBq60Co       2.0 kBq226Ra      2.5 kBq
Typical Minimum Detectable Activities (soil)Buried 150 mm deep 137Cs     107 kBq60Co       31 kBq226Ra      87 kBq
Operating Temperature Range +5°C to +35°C
Frame Weather proof, anodised carry frame
Features Trimble GeoXT hand held GPS computer and RadSurvey software. MCA and gross counting mode
Included 1GB SD card, case, battery charger, and all leads
